IO Modual
39
Analog Output Ratings (AO)
Output Voltage/Current Range 0-20mA/4-20mA, 0-5V/1-5V user selectable
Accuracy 0.5% full scale
Temperature Drift 50ppm/
℃
typical
Open Circuit Voltage 15V
Isolation Voltage 500V
Analog Input(AI)
Input Voltage/Current range 0-20mA/4-20mA, 0-5V/1-5V user selectable
Resolution 16bit
Accuracy 0.2% full scale
Maximum Input Voltage/Current Voltage: 5V; Current:20mA
Temperature Drift 50ppm/
℃
typical
Isolation Voltage 500V
Internal 24V Power Source
Output Voltage 24Vdc
Output Current 42mA (Maximum)
Maximum Load 21digital inputs
Standards
Safety IEC 61010-1, UL 61010-1
EMC IEC 61000-4/-2-3-4-5-6-8-11
Suitable Condition
Operating Temperature -25
℃
to +70
℃
Storage Temperature -40
℃
to +85
℃
Humidity Rating 5
％
to 95
％
non-condensing
Weight AXM-IO1: 90g; AXM-IO2: 80g; AXM-IO3: 85g
Power Consumption AXM-IO1: 1W; AXM-IO2: 1.3W; AXM-IO3: 0.8W
