IO Modual

2.1 Appearance and Dimensions

Figure 2-1 shows a structure conguration of IO module.

Figure 2-1 structure conguration of IO modules

2.2 Installation Method

Environmental

Please check the environment temperature and humidity to ensure the

satisfaction of Acuvim II meter and IO modules requirement before the

①

Enclosing

⑤

Installation screw

②

Wiring Terminals

⑥

Counterpart of clip

③

Linking pins

⑦

Installation clip

④

Linking socket

①

②

③

⑤

⑥

90mm

55.6mm

④

⑦

⑤

②

19.5mm
