22
IO Modual
IO module is SOE disabled. If register is “1”, then AXM-IO11 (AXM-IO1
module in sub address 0) is SOE enabled. If register is “2”, then AXM-
IO21 (AXM-IO2 module in sub address 0) is SOE enabled. If register is
“3”, then AXM-IO31 (AXM-IO3 module in sub address 0) is SOE enabled.
If register is “4”, then AXM-IO12 (AXM-IO1 module in sub address 1) is
SOE enabled. If register is “5”, then AXM-IO22 (AXM-IO2 module in sub
address 1) is SOE enabled. If register is “6”, then AXM-IO32 (AXM-IO3
module in sub address 1) is SOE enabled. Only one IO module can be SOE
enabled at one time. If the IO module is not linked to AcuivmII power
meter, then it is meaningless to enable this IO module’s SOE function.
Figure 3-4 shows the parameters setting of IO module’s SOE function.
