Installation & Operation Manual - Model AVC5000
Contents of this Manual are Subject to Change Without Notification Page 11
SECTION 3 – PHYSICAL DIMENSIONS & WEIGHTS
3.1 Round Valve Sizes
3.2 Rectangular Valve Sizes
Note: All dimensions are to the “outside” and have a tolerance of +/- .062” (1.6mm).
Valve Model
Dimensions
Weight
“D”
“L”
“H”
Stainless Steel
Aluminum
in.
mm
in.
mm
in.
mm
Lbs.
kg
Lbs.
kg
AVC5100-06
5.88
149
22
559
10
254
13
5.9
9
4.1
AVC5100-08
7.88
200
24
610
13
381
16
7.3
12
5.4
AVC5100-10
9.88
250
24
610
15
432
20
9.1
14
6.4
AVC5100-12
11.88
300
27
686
17
483
26
11.8
16
7.3
AVC5100-14
13.88
350
30
762
19
533
30
13.6
20
9.1
Valve Model
Valve Width “W”
Weight
Ref Diagram
Stainless Steel
Aluminum
in.
mm
Lbs.
kg
Lbs.
kg
AVC5200-18
17.88
454
43
19.5
26
11.8
AVC5200-24
23.88
607
49
22.2
29
13.2
AVC5200-36
35.88
911
97
44.0
59
26.8
AVC5200-48
47.88
1216
109
49.4
69
31.3
“H”
12”
(305mm)
“D”
“L”
19”
483mm
30”
762mm
“W”
11.88”
302mm
