APPENDIX A: DOCUMENT REVISION HISTORY
Revision History
ECN #
New Rev.
New Filename
2301
J
AVC5000 MANUAL REV J - JUNE 2017.docx
Cover
Revised Revision and Date
2.0
Sensor material for 316SS Polycarbonate, UL94-VO
ECN #
New Rev.
New Filename
2301
G
AVC5000 MANUAL REV G - NOV 2017.docx
Cover
Revised Revision and Date
6.6.1
Revised Dashboard picture to include Hibernate Mode Active
6.6.2
Revised Airflow Volume Gauge picture to include Hibernate Mode Active
6.6.4.1.2
Revised Setpoint Source picture Jumper Settings Descriptions
6.6.4.2.5.9
Revised Configure Alarms picture to include Select Status Indicator Color option (2 pictures)
2276
F
AVC5000 MANUAL REV F - AUG 2017.docx
Section
Description of Change
6.6.4.2.3
Revised descriptive text to include additional BACnet control over DI-1 (BV3) and DI-2 (BV4)
Revised graphics to include additional BACnet control over DI-1 (BV3) and DI-2 (BV4)
6.6.4.2.4
Revised graphics to include additional BACnet control over DI-1 (BV3) and DI-2 (BV4)
6.6.4.2.5.8
Added Energy Conservation Alarm Description
6.6.4.2.5.9
Was previously 6.6.4.2.5.8
Revised graphics to include additional BACnet control over DI-1 (BV3) and DI-2 (BV4)
Revised graphics to include additional Energy Conservation Alarm Settings
Section 7
Revised BACnet Point List to include additional BACnet control over DI-1 (BV3) and DI-2 (BV4)
Appendix B
Removed the AVC5000 Configuration Form and replaced with description for using the AVC
Config Form within the AccuValve Estimate-Order Spreadsheet to provide the configuration
info.
2201
E
AVC5000 MANUAL-February 2017.DOC
Section
Description of Change
TOC
Revised to reflect changes below
2.0
Changed the max operating temp from 150 deg. F to 165 deg. F
Revised Table 1 to remove the discontinued Galvanized Material
3.2
Added the weights for Aluminum Rectangular Valves to table
4.1
Revised figure showing installation of the optional flanged valve
6.6.1
Revised dashboard figure to show the latest
6.6.4.2.3
Added note at the end of Example 2
6.6.9
Replaced strip chart figure with new figure showing the latest, which includes face velocity
6.6.10.1.1
Added section to describe the “Actuator Feedback Calibration”
6.6.10.1.2
Revised System Utility window and added descriptions for each utility
7.0
Revised the BACnet point table to include; AV5 and AV6 which were recently added
Appendix C
Revised factory default valves for Setpoint Mode
Appendix D
Revised factory default values for Fume Hood Mode
2055
D
AVC5000 MANUAL-SEPTEMBER 2015.DOC
Section
Description of Change
TOC
Revised to reflect changes below
6.6.4.1.1
Revised Figure; Changed “Default BACnet Airflow Setpoint” to “Factory Default Airflow
Setpoint”
6.6.4.2.1.5
Hibernate Mode; Section was rewritten to clarify description of performance.
6.6.4.2.5
Configure Alarms; Section was rewritten to clarify alarm descriptions
6.6.4.2.5.7
Alarm Mute Reminder; Section rewritten to clarify operation
