Ace AT Series - Spare Parts for AT48, AT60

Page | 20
Spare Parts for AT72
Recommended
spare Qty.
Item
Description
GRG-
DV32220099.00
Speed Reducer - GRG-DVLMQ832-600-RD4-56C
600:1 Ratio, Double Reduction, 1.5" Dia. Output Shaft,
56-C Face, Fill Oil Level Based on Output Shaft
Being Up, Mobil GlyGoyle 460 PAG Pre-filled
with Vertical Low Feet Installed
098000.00
Motor - 1/2HP, TENV, 1750RPM, 90VDC
Removable base
1173717
DC Controller - BC140, 90VDC Speed Control
Non-Reversing, Nema 1 Enclosure, 1/2HP Max.
1174279
Resistor - BR0025, for 1173717 DC Controller
Includes Fuse, for 1/2HP DC Motor
46197
Bottle Jack - 12 Ton, Hydraulic, 8 15/16" T0 23 5/8"Lift
Stroke 11 1/8", 2 Stage Ram
6436K23
Shaft Collar - Two Piece, 1 1/2" Bore, 2 3/8" OD
9/16" Width, Steel
VG-JS3-075-125-
20
Guide Rail - 3/16 x 3/4" J Leg, 3/4" Face, 20Ft
