MODE NO. 9 10 11 12
RESOLUTION 800 x 600 832 x 624 1024 x 768 1024 x 768
Dot clock(MHz) 50 57.283 65 75
f h 48.077kHz 49.72kHz 48.363kHz 56.48kHz
H-Total ( us ) 20.80 (1040dots) 20.11(1152 dots)
20.677(1344 dots)
17.71(1328 dots)
H-Sync ( us ) 2.400 ( 120 dots) 1.12(64 dots) 2.092(136 dots) 1.81(136 dots)
H-B-P ( us ) 1.280 (64 dots) 3.91(224 dots) 2.462(160 dots) 1.92(144 dots)
H-Active ( us ) 16.00 (800 dots) 14.52( 832 dots )
15.754(1024 dots)
13.65(1024 dots)
H-F-P ( us ) 1.120 (56 dots) 0.56(32 dots ) 0.369(24 dots) 0.32(24 dots)
f v 72Hz (72.188) 74.55Hz 60.004Hz 70.07Hz
V-Total (ms ) 13.85 (666 lines) 13.41(667 lines)
16.666(806 lines) 14.27(806 lines)
V-Sync ( ms ) 0.125 (6 lines) 0.06(3 lines) 0.124(6 lines) 0.11(6 lines)
V-B-P (ms ) 0.478 (23 lines) 0.78(39 lines) 0.600(29 lines) 0.51(29 lines)
V-Active ( ms ) 12.48 (600 lines) 12.55 (624 lines)
15.880(768 lines) 13.60(768 lines)
V-F-P ( ms ) 0.770 ( 37 line )
0.02(1 line) 0.062(3 lines) 0.05(3 lines)
SYNC. H/V + / + +/+ -/- -/-
POLARITY
SEP . SYNC Y2 Y Y Y
