- 14 -
MODE NO. 13 14 15 16
RESOLUTION
1024 x 768 1280 x 1024 1280 x 1024 1152 x 864
Dot clock(MHz)
78.75 108 135 108
f h 60.02kHz 63.981kHz 79.976KHz 67.5 KHz
H-Total ( us ) 16.66(1312 dots) 15.630 (1688 dots)
12.504 (1688 dots)
14.815(1600 dots)
H-Sync ( us ) 1.22 (96 dots) 1.037 (112 dots)
1.067 (144 dots) 1.185(128 dots)
H-B-P ( us ) 2.23 (176 dots) 2.296 (248 dots)
1.837 (248 dots) 2.370(256 dots)
H-Active ( us ) 13.00 (1024 dots) 11.852 (1280 dots)
9.481 (1280dots) 10.667(1152 dots)
H-F-P ( us ) 0.20 (16 dots) 0.444 (48 dots) 0.119 (16 dots) 0.593(64 dots)
f v 75.03Hz 60.020Hz 75.025 Hz 75.06 Hz
V-Total (ms ) 13.33 (800 lines) 16.661 (1066 lines)
13.329 (1066 lines)
13.333(900 lines)
V-Sync ( ms ) 0.05 (3 lines) 0.047 ( 3 lines) 0.038 (3 lines) 0.044(3 lines)
V-B-P (ms ) 0.47 (28 lines) 0.594 ( 38 lines)
0.475 (38 lines) 0.474(32 lines)
V-Active ( ms ) 12.80 (768 lines) 16.005 (1024 lines)
12.804(1024 lines)
12.800(864 lines)
V-F-P ( ms ) 0.02 (1 lines) 0.016 (1 line ) 0.013 (1 lines) 0.015(1 lines)
SYNC. H/V +/+ +/+ +/+ +/+
POLARITY
SEP . SYNC Y Y Y Y
