- 30 -
Assembly process
Picture Description
1. Get the inverter board and inverter cable
2. Insert inverter cable to inverter board.
3. Assembly inverter board and shielding
cover
1. Insert keyboard cable on the main board
2. Insert button cable on the main board.
3. Insert LCD cable on the main board.
To Next Page
