Acer AR320 F2 - Chassis Cover Removal and Installation; Removing the Top Cover

89 pages

To Next Page

To Previous Page

Chassis

Cover

Removal

and

Installation

Removing the top cover

1. Press the top cover release button located oh the edge of server.

2. Slide the top cover toward the rear of the chassis to disengage it.
