Chapter 1 1
Overview
Main Board
Description
Size Max. 244 mm x 244 mm, MicroATX
Processor • Socket type: Intel socket T LGA775 pin
• Socket quantity: one
• Intel Prescott 775 / Smithfield / Cedar Mill / Presler / Conroe, core speed
533/800/1066MHz
System Chipset • GMCH: Intel G965
• ICH: Intel ICH8DH
• Super I/O: ITE8718
Memory • Four DDR2 connectors
• Capacity:
• 256MB to 1GB DDR2 800/667/533 unbuffered SDRAM module support
• Feature support 2GB DDR2 800/667/533 unbuffered SDRAM module
when memory sample passes validation
• Max. 256MB to 4GB memory support
• Feature support to 8GB max. memory support when memory sample
passes validation.
• Dual-channel function enabled when plugging in two same memory
size DDR2 memory modules
Onboard Graphic
Solution
• Intel G965 on-die graphic (Intel GMA X3000) solution
• DVMT 4.0 technology support
• Enhanced 3D and clear video technology support
• Dual view function supported by Intel ADD2/ADD2+
• One D-sub VGA port on the rear side
PCI Express / PCI
Slots
• One PCI Express x16 slot
• One PCI Express x1 slot
• Two PCI 2.3 slots
FDD • One slot for FDD
• 1.44MB / 3 mode 3.5” devices support
SATA • Six SATA slots
• Storage type support:
• HDD / CD-ROM / CD-RW / DVD-ROM / DVD-RW / DVD+RW / DVD Dual /
DVD SuperMultiPlus / Blue-Ray ODD
System Specification
Chapter 1
