Acer ASPIRE ONE 1410 - Replacing the Main Board

106 Chapter 3
Replacing the Main Board
1. Slide the main board external connector edge in first to the lower case.
2. Replace the five screws to secure the mainboard to the lower cover.
Screw List
Step Screw Quantity Screw Type
Main Board Assembly 2x3 5
