Acer ASPIRE ONE 1410 - Removing the LED Board

66 Chapter 3
Removing the LED Board
1. See “Removing the Upper Cover” on page 58.
2. Unlock and remove the LCD board FCC.
3. Remove the single screw securing the LED Board to the Lower Cover.
Screw List
Step Screw Quantity Screw Type
LED Board
Disassembly
2*3 1
