Aspire TC-780 Desktop Computer Service Guide 43
Removing the SSD Module
1. Remove the screw securing the SSD module to the mainboard.
2. Remove the SSD module from the mainboard.
Quantity Color Torque Part Number Screw Type
1 Silver 1.5 ± 0.3 kgf-cm 86.NBY01.003
Note: WEEE Annex VII component. A circuit board >10 cm2 has been highlighted
with the yellow rectangle as shown above. Please follow local regulations for disposal
of detached circuit boards.
