Acer Aspire TC-780 - Removing the Front I;O and Card Reader Assembly

46 Aspire TC-780 Desktop Computer Service Guide
Removing the Front I/O and Card Reader Assembly
1. Disconnect the front I/O board and card reader board cables from the mainboard.
2. Remove the screw securing the front I/O and card reader bracket to the chassis.
Quantity Color Torque Part Number Screw Type
1 Silver 6.0 ± 0.5 kgf-cm 86.SPZD1.003
