Aspire AX1430 Service Guide 15
Onboard Floppy Controller Enables or disables the onboard floppy controller. Enabled
Disabled
Serial Port1/2 Address Specify the base I/O port address and interrupt request address of
serial port 1 or 2.
Disabled
3F8/IRQ4
2F8/IRQ3
3E8/IRQ4
2E8/IRQ3
Serial Port2 Mode Select a mode for serial port 2. Normal
IrDA
ASK IR
Parallel Port Address Specify the parallel port (LPT1) base address. Disabled
378
278
3BC
Parallel Port Mode Select a mode for the parallel port. Normal
EPP
ECP
EPP+ECP
Parallel Port IRQ Select a parallel port IRQ interrupt. IRQ5
IRQ7
ECP Mode DMA Channel Select an ECP mode. DMA1
DMA3
Parameter Description Option
