Connector pin assignment
15
6
10
11
15
15-pincolordisplaysignalcable
PINNo. Description PINNo. Description
1 Red 9 +5V
2 Green 10 Logic ground
3 Blue 11 Monitor ground
4 Monitor ground 12
DDC-serialdata
5 DDC-return 13 H-sync
6 R-ground 14 V-sync
7 G-ground 15 DDC-serialclock
8 B-ground
