5
English
Base view
# Item Description
1 Hard disk bay Houses the computer's hard disk (secured
with screws).
2 Battery release latch Releases the battery for removal.
3 Battery bay Houses the computer's battery pack.
4 Battery lock Locks the battery in place.
5 Cooling fan Helps keep the computer cool.
Note: Do not cover or obstruct the opening
of the fan.
6 Memory compartment Houses the computer's main memory and
mini PCI Card.
