Acer K10 - Projector Overview; Component Identification

3
English
Projector Overview
Projector Outlook
Front / upper side
Rear side
# Description # Description
1 Control panel 3 Projection lens
2 Focus ring 4 Elevator foot
# Description # Description
1 DC IN connector 4 Kensington lock port
2 Composite video input connector 5 Tripod socket
3 PC analog signal/HDTV/Component
video input connector
