19
3. Firmware Upgrade Process
1. Materials list and connection
USB
port driver
ISP TOOL
2.Install USB driver.
When insert the USB cable to PC USB port, will pop up a Hardware Wizard to help you install the USB driver if you use
this ISP board first time.it can auto install success by itself
Remark: The USB driver files path: D:\FTC100103(Mstar)\FTCUSB.INF
After installation the USB serial port driver, please check the port. Look the properties of “my Computer”
FW
USB
HDMI
DVI to HDMI
ISP JIG:
715GT089-C
Power cable Power cable
CER_QG241Y_A2H
VSL_RTD2522AR_TP
M238WF1_HVN01_U_
20200722_V0.02_150A
Reduce_ERP
