4
1. Exploded view diagram with list of items
Item Description TPV Part No.
ACER Part
No.
5 750GBV23810CAFN000 LCD TPM238WF1-HVN01.U 00CA BH TPV #N/A
8 PLPCJE541KVP8 ADAPTER BOARD G9541-P0A-X-000-0010 #N/A
10 CBPRITMC0Q6 MAIN BOARD #N/A
12 KEPCLQA6 KEY BOARD 55.TCCM2.003
395G179W30P1520000 FFC CABLE 30P-30P 280MM(MB TO PANEL) NA
To Next Page
