Acer S191HQL - Page 10


8
D. Flat Panel Connector
Connector : CN409
Pin Signal Pin Signal
1 GND 26 POL
2 GND 27 CSC
3 GND 28 H2DOT
4 GND 29 GND
5 GND 30 ICLK_RESET
6 GND 31 ICLK1
7 GND 32 ICLK2
8 GND 33 ICLK3
9 GND 34 ICLK4
10 GND 35 IVDD-O
11 GND 36 IVDD-E
12 LVCLK- 37 FLK2
13 LVCLK+ 38 FLK1
14 GND 39 GND
15 LV2- 40 SDA
16 LV2+ 41 SCL
17 GND 42 GND
18 LV1- 43 VIN
19 LV1+ 44 VIN
20 GND 45 VIN
21 LV0- 46 VIN
22 LV0+ 47 VIN
23 GND 48 VIN
24 SOE 49 GND
25 POL2 50 GND
