Acer S191HQL - Page 14


12
1.3.4.2 Factory Assigned Display Modes:
Mode Resolution

VGA
640x480 60Hz
640x480 72Hz
640x480 75Hz
SVGA
800x600 56Hz
800x600 60Hz
800x600 72Hz
800x600 75Hz
XGA
1024x768 60Hz
1024x768 70Hz
1024x768 75Hz
VESA 1152x864 75Hz
1280x960 60Hz
1280x720 60Hz
WXGA
1366x768 60Hz
1280x800 60Hz
DOS 720x400 70Hz
SXVGA
1280x1024 60Hz
1280x1024
75Hz
VGA 640x480 67Hz
SVGA 832x624 75Hz
MAC
1152x870
75Hz

1.4 Flat Panel:
1.4.1 General Requirements:
The panel shall be a FULL HD resolution 18.5” diagonal TFT-LCD.
1.4.2 Polarizer Hardness:
The front polarizer should have hard coating (3H) and anti-glare treatment.
1.4.3 Backlight Requirements:
1.4.3.1 General Requirements: (For LCD BM185WH2-T2BB)
Parameter Symbol Condition
Values
Unit Notes
Min. Typ. Max.
LED : 1,7
LED String Current Is - 110 120 mA 2,7
LED String Voltage Vs 45.0 48.0 51.0 V 3,7
Power Consumption PBar - 10.6 11.2 Watt 4,6,7
LED Life Time LED_LT 30,000 - - Hrs 5,7
