Chapter 1 29
Hardware Specifications and Configurations
Throttling 50%: On= 99 C; OFF=93 C
OS shut down at 105 C; H/W shot down at 110 .C
Processor
Item Specification
CPU type Intel® Core™2 Duo Mobile Processor T7300/T7500/T7700/T7800
(4 MB L2 cache, 2/2.2/2.4/2.6 GHz, 800 MHz FSB), or T7100/
T7250 (2 MB L2 cache, 1.8/2.0 GHz, 800 MHz FSB)
Intel® Core™2 Duo Mobile Processor T5250/T5450 (2 MB L2
cache, 1.60/1.73 GHz, 533 MHz FSB)
Intel® Celeron® M processor 530/540/550 (1 MB L2 cache, 1.73/
1.86/2.0 GHz, 533 MHz FSB)
Intel® Pentium® Dual-Core processor T2310/T2330 (1 MB L2
cache, 1.46/1.6 GHz, 533 MHz FSB) or higher (for selected
models)
Core logic Mobile Intel® PM965/GM965/960 + ICH8M Express Chipset
CPU package Socket M (FCPGA6)
CPU core voltage 1.0375V to 1.3V
CPU Fan True Value Table
DTS(degree C) Fan Speed (rpm) Acoustic Level (dBA)
45-50 0-3000 29
55-66 0-3300 33
68-74 3300-3800 38
78-83 3800-4100 40
86-91 4100-4800 40
BIOS
Item Specification
BIOS vendor Phoenix
BIOS Version 1.02 (MP version)
BIOS ROM type SST/AMD 1MB CMOS Boot Block Flash Memory
BIOS ROM size 1M byte FLASH ROM SST
BIOS package 10-lead TSOP (10mmx20mm)
Supported protocols ACPI 1.0b/2.0/3.0 compliance, PCI 2.2, System/HDD Password
Security Control, INT 13H Extenstions, PnP BIOS 1.0a SMBIOS
2.4, BIOS Boot Specification, Simple Boot Flag 1.0, Boot Block,
PCI Bus Power Management Interface Specification, USB
Specification 1.1/2.0, IEEE 1394 1.0, USB/1394 CD-ROM Boot Up
support, PC Card Standard 1995 (PCMCIA 3.0 Compliant Device),
IrDA 1.0, Intel AC97 CNR Specification, WfM 2.0, PXE 2.1, Boot
Integrity Service Application Program Interface (BIS) 1.0, PC99a
and Mobile PC2001 Compliant
BIOS password control Set by setup manual
Item Specification
Cache controller Built-in CPU
°°
°°
