Acer V193 - Page 29

- 29 -
14
Stick two Al foils on the
right and under between
pane land Main-BTK
Stick an Al foils on the up
between panel and Main-
BTK
16
Lock screws of side on
Main-Chassis with
2/4,based on DVI.
Attention the order by
one to four.
17
Assemble the L-SHD the
correct position reference
on the picture
3
4
1
2
