Acer V203H

15
Main Board Diagram
Flash Memory
PM25LV010A-100SCE
(U402)
Panel Interface
(CN301)
Crystal
12MHz
(X401)
Keypad Interface
(CN402)
Scalar IC NT68667FG
(Include MCU, ADC, OSD)
(U401)
D-Sub
Connector
(CN101)
H sync
V sync
RGB
DVI
Connector
(CN102)
D-Data
D-Clock
EEPROM
M24C16
(U403)
