Acer X193HQ - Page 26

- 26 -
4 Turn over the
monitor ,dismantle the
Rear cover from the
monitor.
Screw-driver：
5.0±1.0Kg*cm
Screw head:
＃2
Don’t draw the BZL
5 Disassembled the ctrl
BD wire shielding and
one acetic tapes.
6 Tear off these two
acetic tapes.
Kick off the wire.
7 Take the entire internal
mechanism from Bezel
and then put it on the
cushion.
8 Tear off these four AL
tapes.
