7. Wide Mode: You can select which screen aspect you are using. The options are Full,
Aspect, 1:1 and 21:9.
8. PIP/PBP: The options for PIP/PBP Mode are Off, PIP Large, PIP Small, and PBP. You
can also adjust the PIP Position, Sub Source, Source Swap, and Audio Source.
Note: PIP/PBP is not supported while FreeSync Premium is "On".
9. Hot Key Assignment: Select the function of Hot Key 1 or Hot Key 2.
10. DDC/CI: Allows the monitor settings to be set through the software on the PC.
Note: DDC/CI, short for Display Data Channel/Command Interface, which
allows monitor controls to be sent via software.
11. HDMI Black Level: You can select the level of blackness under HDMI source.
12. Quick Start Mode: Select Off or On. The default is "Off". Turn on to speed up boot speed.
13. DSC: The default is "On", Support DP&HDMI & DP ALT has DSC Function.
14. Image Retention Refresh: To reduces the risk of image retention occurrence, if the
monitor has been in use for Image Retention Refresh more than 4 hours, Image
Retention Refresh, will start automatically after the monitor is turned off. You can also
start Image Retention Refresh manuall via OSD menu.
When Image Retention Refresh process begins, the monitor will display warning
message the power LED starts flashing blue and amber light alternately.
When the power LED lights off, this indicates the Image Retention Refresh process is
complete, the duration of the Image Retention Refresh is around 5 minutes.
Note: During Image Retention Refresh process don’t turn off monitor and don’t
unplug the power.
15. USB Port Select: Set the USB port type to C-Type or B-Type or Auto.
Note: 1. DSC = "On" is Default
Support DP, DP ALT & HDMI.
All can support max resolution must refer to the "Max Refresh Rate".
2. DSC = "Off"
For some devices such as mobile phones, DSC needs to be set to Off
to display properly.
Resolutions that can be supported will depend on the capabilities of
the graphics card, and may not be able to display
3840X2160@240Hz.
