-10-
RESET
A RESET button is accessible from the back panel.
Use exclusively a 2mm diameter non-metallic object to press the button.
EARTH GROUNDING
There are 2 ways to connect the product to the ground:
- Use the power terminal block on the front panel
- Use the grounding tab (0.81x6.35 mm) on the right side.
For efficient grounding we recommend using a braided metal wire (not supplied) and
therefore using the grounding lug.
