Acksys AirLink V2 - WI-FI INTERFACE PERFORMANCE; Transmit Power Output; Receive Sensitivity Levels

-18-
Wi-Fi interface
Dual band 11n 2T/2R
Radio card output Tx
power
Tolerance ± 2dB
Subtract 2 dBm to get
the value available at
the antenna connector
itself
Modes 1 antenna
(RF chain)
2 antennas
(RF chains)
802.11b/g
19 dBm @ 6M
15 dBm @ 54M
Add 3 dBm to
the values given
for 1 RF chain
802.11a
18 dBm @ 6M
15 dBm @ 54M
802.11gn HT20
20.5 dBm @ 7.2
Mbps (MCS 0)
18 dBm @ 72.2
Mbps (MCS 7)
802.11gn HT40
20.5 dBm @ 15
Mbps (MCS 0)
18 dBm @ 150
Mbps (MCS 7)
802.11an HT20
18 dBm @ 7.2 Mbps
(MCS 0)
15 dBm @ 72.2
Mbps (MCS 7)
802.11an HT40
18 dBm @ 15 Mbps
(MCS 0)
15 dBm @ 150
Mbps (MCS 7)
Rx sensitivity (radio
card input)
Tolerance ± 2dB
Add 2 dBm to get the
value available at the
antenna connector
802.11b
Non disponible
802.11b/g
-94 dBm @6M
-80 dBm @54M
802.11a
-96 dBm @6M
-84 dBm @54M
802.11gn HT20
-92 dBm @ 7.2Mbps (MCS 0)
-76 dBm @ 72.2 Mbps (MCS 7)
802.11gn HT40
-90 dBm @ 15 Mbps (MCS 0)
-73 dBm @ 150 Mbps (MCS 7)
802.11an HT20
-96 dBm @ 7.2Mbps (MCS 0)
-75 dBm @ 72.2 Mbps (MCS 7)
802.11an HT40
-91 dBm @ 15 Mbps (MCS 0)
-72 dBm @ 150 Mbps (MCS 7)
