Aclarus AOWT-7 - Page 18

18
Image 2 Image 3
Inlet and Outlet Shown
Drain (Far right) for winterization etc… shown
20” Activated Carbon prior to discharge shown
Inlet
Outlet
Drain
A
B
C
A – Fill Water Column here by unscrewing top and adding water
B – Sight Line for Water Column – Ensure it is always at halfway up sight line
C – Check Silica air dryer regularly. When 75% of the orange silica changes to green,
replace and recharge as directed
