ACME SUPERNOVA - Page 15

- 14 -
Rotating Gobo Wheel 1
Rotating Gobo Wheel 2
Slot
Name
Part Number
Slot
Name
Part Number
Open
Empty
/
Open
Empty
/
1
Broken Circle
3011001474
1
Square Tunnel
3011001481
2
Eccentric Circles
3011001475
2
Clouds
3011001482
3
Dream Tunnel
3011001476
3
Mixed Beams
3011001483
4
Tiny Bubbles
3011001477
4
Multiple Angles
3011001484
5
Square Bar
3011001478
5
Grid
3011001480
6
Linear Breakup
3011001479
6
Diamond Glass A
3015001218
Size of Rotating Gobos (Rotating Gobo Wheel 1)
Slot
Gobo Diameter
Image Area Diameter
Glass Thickness
1~6
34mm+0/-0.2mm
27.5mm
1.1mm
Size of Rotating Gobos (Rotating Gobo Wheel 2)
Slot
Gobo Diameter
Image Area Diameter
Glass Thickness
1~5
34mm+0/-0.2mm
26.5mm
1.1mm
6
31mm+0/-0.2mm
/
2.7mm
