ACMER P1 - Y-axis Belt Assembly; Front Panel Assembly

Required materials: Synchronous belt 2PCS, square gasket 2PCS, m5*8 round head
screw 2PCS
材料：同步带 2PCS、方形垫片2PCS、M5*8半圆头螺丝 2PCS
3. Assemble the y-axis belt
锁Y皮带
Required materials: M5*35 round head screws 4PCS, m5*16 round head screws 2PCS
材料：M5*35半圆头螺丝 4PCS、M5*16半圆头螺丝 2PCS
4. Assemble the front panel
组装前面板
3.1 Pass one end of the timing belt through the pulley and the timing
wheel and out of the tailboard hole
将同步带一端穿过滑轮和同步轮，从尾板孔位穿出
3.2 Pull the timing belt out of the waist hole of the back plate and compress it
with gaskets and screws
将同步带从背板腰型孔拉出，并用垫片和螺丝压紧
09
M5*8 round head screw
