ACMER P1 - Pulley Adjustment

1
2 3 4 5 6
Lock the tank chain fixing holes at the four positions shown in the figure with
countersunk screws
将图示四个位置的拖链固定孔用沉头螺丝锁紧即可
Use an open-ended wrench to rotate the eccentricity of six eccentric nuts of X and Y
axes, and adjust the pulley to the state of just clamping
使用开口扳手旋转X、Y轴共六个偏心螺母的偏心距，调节滑轮至刚好卡紧的状态
6. Pulley adjustment
滑轮调节
11
M3*6 countersunk head screw
