7.11
MEASUREMENT RESULTS
The Measurement Result screen shows
coupling values in both directions, and bolt
values.
The symbol to the left of the coupling values
indicates the angular direction and offset, and
if the values are within tolerance.
Within tolerance (green).
Within double tolerance (yellow
and inverted).
Out of double tolerance (red
and inverted).
When a coupling is in tolerance
in one direction, this is
indicated with a check symbol
at the motor.
Save the measurement result.
To Next Page
