ACOEM EVO - Softcheck

9.1
SOFTCHECK™
INTRODUCTION
A soft foot condition needs to be corrected
before any alignment takes place. If not, the
measurement result will be of no value. It is
more or less impossible to establish if there is
a soft foot condition without using some kind
of measurement tool. The Softcheck program
checks each foot and displays the result in
mm or mils.
The Softcheck program is entered from the
Horizontal Shaft Alignment program.
STARTING THE PROGRAM
Start the Softcheck by touching
its icon in the Shaft Alignment
program.
Place the sensors at the 12 o’clock position.
All the distances must be entered, before
checking for soft foot.
Check that all foot bolts are firmly tightened.
