ACOEM EVO - Technical Specification M3 and

17.1
TECHNICAL SPECIFICATION – M3 AND S3
Art. No. M3 1-0913, S3 1-0914
Housing Material
Anodized Aluminum frame and high impact
ABS plastic over molded with TPE rubber
Operating Temp
-10 to 50°C (14 to 122°F)
Storage Temp
-20 to 70°C ( -4 to 158°F)
Long term storage temp
Room temp. 18 to 28°C (64 to 82°F)
Battery Charging Temp
0 to 40°C (32 to 104°F)
Relative humidity
10 – 90%
Weight
192 g (6,8 oz) with battery
Dimensions
92mm x 77mm x 33mm
(3,6 in x 3,0 in x 1,3 in)
Environmental protection
IP65 (Dust tight and protected against water
jets)
Laser
650 nm class II diode laser
Laser line fan angle
6°
Laser line width (1/e2)
1.6 mm
Laser line divergence (full angle)
0.25 mrad
Laser power
< 1 mW
Measurement distance
Up to 10m
Detector
2nd gen. scientific grade CCD
Detector length
30mm (1,2 in)
Detector angular subtense
30mrad/m (3mm/100mm per meter)
