ACOEM EVO - Machine Defined Data

8.1
MACHINE DEFINED DATA
INTRODUCTION
If the sensors are placed at the same place
each time a machine (or more identical
machines) is measured, it can be convenient
to preload the relevant parameters. The data
that can be preloaded are:
• The name of the specific machine.
• Distances for the machine, the distance
between the sensors (where fixture
points are fixed), the distance between
the center of the coupling and the M-
sensor, the distance between the M-
sensor and the first pair of feet and the
distance between the first and the
second pairs of feet.
• Target Values as feet values or angle
and offset values.
• Tolerances.
NOTE!
When using Machine Defined
Data, the sensors must always
be placed according to the
preloaded distances to get
correct measurement results.
