- Bypass path: VSWR less than 1.1:1, 1.8-30 MHz continuously, 200 W maximum;
- Output (antenna) impedance matching capability: VSWR up to 3:1 or higher.
g) RF Gain: 11dB typically, frequency response less than 1dB (50 to 70 W drive power for rated
output).
h) Primary Power: 85-132 V/170-264 V ac (100, 110, 120, 200, 210, 220, 230 & 240 V nominal taps),
+10% -15% tol.), 50-60 Hz, single phase, 1200 VA.
i) Complies with CE safety and electromagnetic compatibility requirements as well as FCC-regulations
(10 & 12 m band locks provided).
j) Size & Weight (operating): WxDxH: 402x315x166mm, 18kg (15.83x12.4x6.5 inches, 39.7Lbs).
k) Operating environments:
- Temperature range: 0 to +50 degrees Celsius;
- Humidity: up to 95% @ +35 degrees Celsius.
- Height: up to 3000 m above sea level without output deterioration.
6-2. Functions
a) Antenna Impedance Matching Process: aided by a plate-load True Resistance Indicator (TRI).
b) Two antenna outputs selectable by a button on the front panel.
c) Protections:
- Cover interlock for operator’s safety;
- Inrush power-on current limited to the nominal consumption;
- Control grid, screen grid, and plate currents;
- T/R sequencing;
- Antenna relay contacts, including RF power induced in antenna from another nearby transmitter;
- Antenna matching quality;
- Reflected power.
d) LED bar-graphs for forward peak power and reflected power.
e) Service visualization of grid 1 DC current, grid 2 DC voltage, and plate DC current.
f) Tube: a single Svetlana 4CX800A (GU74B) high-performance ceramic-metal tetrode with plate
dissipation of 800 W, grid driven, forced air-cooling.
