12
See Detail Below
Antenna Motor
Cam
Gear Assembly
Antenna
Rivet, Plastic
Radiant Heater
Alignment Arrows
Gear Assembly
Antenna
Rivet, *Plastic
Antenna Motor
Cam
*Note: Plastic Rivet
cannot be reused.
Note: Requires 15/16” (26mm)
Deep Socket
Flat Washer
Multi-Wave Spring Washer
Lock Nut
OVEN CONSTRUCTION-
