ACP JET514 - Test Modes; Error Codes

Test Modes
!
WARNING
To avoid risk of electrical shock, personal injury, or death, disconnect power to oven and discharge capacitor
before servicing, unless testing requires it.
October 2014 16500055
©2014 ACP, Inc.
9
Error Codes: During operation, the display may show the following service codes:
Note: Before scheduling service for any error codes, instruct customer to
unplug oven for 1 minute, reconnect power, and re-test. If unit operates
properly, no service call is required.
DISPLAY
DESCRIPTION
CORRECTIVE ACTION
Error Code: 2
Shorted Touch Panel
or
Failed H.V. Board
-Replace H.V. Board
-Replace Touch Panel
Error Code: 3
Failed H.V. Board
-Replace H.V. Board
-Replace Touch Panel
Error Code: 4
Failed H.V. Board
-Replace H.V. Board
-Incorrect H.V. Board Installed in Oven
Error Code: 5
Shorted Touch Panel
Note: If touch panel is pressed for more than
30 seconds, this error code will appear.
-Disconnect Oven From Power Supply
-Disconnect Side Touch Panel Connector
From Display Board.
-Reconnect Oven to Power Supply
-If “Error Code: 5” Reappears After 30
Seconds,
Replace Top Touch Panel.
-If “Error Code: 5” Does Not Reappear After 30
Seconds, Replace Side Touch Panel.
Error Code: 6
Options Scrambled
Replace H.V. Board
Error Code: 7-O
Open RTD
Check RTD and Wiring to H.V. Board
Error Code: 7-S
Shorted RTD
Check RTD and Wiring to H.V. Board
Door Open
Door Interlock
Primary Switch
-Verify Latch Mechanism Moves Freely On
Door.
-Verify J1 Connector On Display Board Is
Properly Seated.
-Test Interlock Switch Assembly and Perform
Door Adjustment If Necessary.
-Replace Interlock Switch Assembly.
