ACP MRX2QT - Oven Construction: Antenna Box

OVEN CONSTRUCTION – ANTENNA BOX
CAREFULLY PRY MICA COVER OUT OF
POSITION USING SECURING TAB. HELD IN
WITH HIGH TEMP GASKETS
LOOSEN 2 FRONT SCREWS
AND REMOVE 2 BACK SECURING
TABS
MICA COVER REMOVAL, AFTER FORCED AIR PLATE REMOVED
ANTENNAS
(From Inside Cavity)
15
