APPENDIX A - RCL-100D SPECIFICATIONS (with
URC-102 Controller)
Specification
12V Unit
24V Unit
Mirror diameter
4in (10.16cm) X
2.75in (6.99cm)
4in (10.16cm) X
2.75in (6.99cm)
Rated voltage (Volt)
12- 16 VDC
24- 31 VDC
Rated current (A)
10
5
Applicable lamp
55W halogen
Lamp X 2
(base –G6.35)
JCD12V-55WDX
70W halogen
Lamp X2
(base –G6.35)
JDC24V-55WDX
Peak beam candle
power (candela)
200,000
160,000
Beam spread
(degrees)
Horizontal 7°,
Vertical 5°
Horizontal 7°,
Vertical 5°
Elevation angle
(degrees)
Up 9°, Down 17°
Up 9°, Down 17°
Turning angle
(degrees)
360°
360°
Elevation speed
4° per second
6° per second
Turning speed
Fast 28° per second,
Slow 15° per second
Fast 28° per second,
Slow 15° per second
Weight
7.15lbs (3.24 kg)
7.15lbs (3.24 kg)
Interconnect cable
15ft (4.57M)
15ft (4.57M)
*All specifications are nominal values
