APPENDIX D - PRODUCT COMPONENTS
Product No. 1930.3 - RCL-100D 12 V Searchlight Installation Kit
includes:
Description
Quantity
ACR Part Number
Searchlight, RCL-100D, 12 V
1
A3-06-1106-3
Kit, Nylon Washers (4)
1
A3-06-1940
Connector, “F”
2
A1-03-0220
Cable, Coaxial
15ft
A2-07-0002-6
Master Controller, URC-102
1
A3-06-2231
Connector, "In-Line"
8
A1-03-0222
Point Pad™, URP-102 with
Surface Mount Case
1
A3-06-2230
Case, Flush Mount
1
A1-18-1875-2
Gasket, Surface Mount
1
A1-25-0140-1
Gasket, Flush Mount
1
A1-25-0140-2
U Clamp
2
A1-17-1366
Nuts, Nylon-lock
2
A1-05-0776
Washers
2
A1-05-0777
Warranty Card
1
A1-20-1019
Product Support Manual
1
Y1-03-0138
Mounting Templates
1
Y1-03-0138-1
Product No. 1931.3 - RCL-100D 24 V Searchlight Installation Kit
includes:
Description
Quantity
ACR Part Number
Searchlight, RCL-100D, 24 V
1
A3-06-1106-4
Kit, Nylon Washers (4)
1
A3-06-1940
Connector, “F”
2
A1-03-0220
Cable, Coaxial
15ft
A2-07-0002-6
Master Controller, URC-102
1
A3-06-2231
Connector, "In-Line"
8
A1-03-0222
Point Pad™, URP-102 with
Surface Mount Case
1
A3-06-2230
Case, Flush Mount
1
A1-18-1875-2
Gasket, Surface Mount
1
A1-25-0140-1
Gasket, Flush Mount
1
A1-25-0140-2
U Clamp
2
A1-17-1366
Nuts, Nylon-lock
2
A1-05-0776
Washers
2
A1-05-0777
Warranty Card
1
A1-20-1019
Product Support Manual
1
Y1-03-0138
Mounting Templates
1
Y1-03-0138-1
