Acrel ACR10R Series User Manual

`
- 8 -
6.2.1Power parameter interface
Note: three-phase three-wire interface without phase voltage and phase separation power
6.2.2 Harmonic parameter interface
Ua 000.0 V
Ub 000.0 V
Uc 000.0 V
F 00.00 Hz
Uab 000.0 V
Ubc 000.0 V
Uca 000.0 V
F 00.00 Hz
Ia 000.0 V
Ib 000.0 V
Ic 000.0 V
PF 1.000
Pa 00.00 kw
Pb 00.00 kw
Pc 00.00 kw
P 00.00 kw
Qa 00.00 kvar
Qb 00.00 kvar
Qc 00.00 kvar
Q 00.00 kvar
Sa 00.00 kVA
Sb 00.00 kVA
Sc 00.00 kVA
S 00.00 kVA
P 00.00 kw
Q 00.00 kvar
S 00.00 kVA
PF 1.000
PFa 1.000
PFb 1.000
PFc 1.000
PF 1.000
MAX DEMAND
00.00 kw
03-03 00:00
AVERAGE
UP 000.0 V
UL 000.0 V
IL 000.0 A
2016-03-04
14 : 50:14
Phase voltage
Line voltage
Current
Active power
Reactive power
Apparent power
Power
Power factor
Maximum demand
Average
Time
Ua 000.0 V
Ub 000.0 V
Uc 000.0 V
F 00.00 Hz
METER SOE
HARM STEUP
ENERG
I/O
Power parameter measurement interface
SET

Acrel ACR10R Series Specifications

General

Model	ACR10R series
Communication	RS485, Modbus-RTU
Protection	IP20
Display	LCD
Power Supply	AC/DC
Rated Current	AC 1A, AC 5A
Frequency	45Hz - 65Hz
Accuracy class	0.5
Power consumption	<5VA
Operating temperature	+55°C
Storage temperature	-25℃~+70℃
Safety	IEC/EN 61010-1
EMC	IEC 61326-1
Relative Humidity	≤95% (non-condensing)
Voltage overload	1.2x rated voltage continuously, 2x rated voltage for 1 second
