minutes, seconds
3126
A Phase Current Total
harmonic distortionmaximum
RO
A Phase Current Total harmonic
content;decimal point digital:2
1
3127
Generation time:
year、month
RO
High 8: year ; low 8: month
1
3128
Generation time:
day,hour
RO
High 8: day ; low 8: hour
1
3129
Generation time:
minutes, seconds
RO
High 8: minutes ; low 8: seconds
1
3130
B Phase Current Total
harmonic distortionmaximum
RO
B Phase Current Total harmonic
content;decimal point digital:2
1
3131
Generation time:
year、month
RO
High 8: year ; low 8: month
1
3132
Generation time:
day,hour
RO
High 8: day ; low 8: hour
1
3133
Generation time:
minutes, seconds
RO
High 8: minutes ; low 8: seconds
1
3134
C Phase Current Total
harmonic distortionmaximum
RO
C Phase Current Total harmonic
content;decimal point digital:2
1
3135
Generation time:
year、month
RO
High 8: year ; low 8: month
1
3136
Generation time:
day,hou
RO
High 8: day ; low 8: hour
1
3137
Generation time:
minutes, seconds
RO
High 8: minutes ; low 8: seconds
1
Note ： 1 、 Read/Write attribute: “ RO ” read only, this parameter use 03H command; “ R/W ”
Read/Write ,system parameter use 10H command, Read in address, which is not listed or without
Read/Write attribute, is forbidden.
2.Meter data adopt fixed_point number, decimal point digital see Address table;voltage/current
harmonic data adopt percentage.
7.5 Communication reading value Vs actual value(Take Val_t as Communication reading
value,Val_sas actual value)
7.5.1Voltage,current,power factor ,frequency
This series measuring value is read out by Modbus-RTU protocol 03 command,each item occupy one
word.Relation between communication value and actual value(secondary side measuring) is shown as below
