Acrel ACR10R Series User Manual

`
- 41 -
electric energy
4
Backward passive
electric energy
68 99 99 99 99 99 99 68 01 02 53 C4 80 16
4
XXXXXX．XX
kvarh
5
Phase A voltage
68 99 99 99 99 99 99 68 01 02 44 E9 96 16
2
XXX
V
6
Phase B voltage
68 99 99 99 99 99 99 68 01 02 45 E9 97 16
2
XXX
V
7
Phase C voltage
68 99 99 99 99 99 99 68 01 02 46 E9 98 16
2
XXX
V
8
Phase A harmonic
voltage
68 99 99 99 99 99 99 68 01 02 47 E9 99 16
2
XXX
V
9
Phase B harmonic
voltage
68 99 99 99 99 99 99 68 01 02 48 E9 9A 16
2
XXX
V
10
Phase C harmonic
voltage
68 99 99 99 99 99 99 68 01 02 49 E9 9B 16
2
XXX
V
11
Voltage vector sum
68 99 99 99 99 99 99 68 01 02 4A E9 9C 16
2
XXX
V
12
Power grid
frequency
68 99 99 99 99 99 99 68 01 02 4B E9 9D 16
2
XX．XX
Hz
13
Phase A current
68 99 99 99 99 99 99 68 01 02 54 E9 A6 16
2
XX．XX
A
14
Phase B current
68 99 99 99 99 99 99 68 01 02 55 E9 A7 16
2
XX．XX
A
15
Phase C current
68 99 99 99 99 99 99 68 01 02 56 E9 A8 16
2
XX．XX
A
16
Phase A harmonic
current
68 99 99 99 99 99 99 68 01 02 57 E9 A9 16
2
XX．XX
A
17
Phase B harmonic
current
68 99 99 99 99 99 99 68 01 02 58 E9 AA 16
2
XX．XX
A
18
Phase C harmonic
current
68 99 99 99 99 99 99 68 01 02 59 E9 AB 16
2
XX．XX
A
19
Current vector sum
68 99 99 99 99 99 99 68 0102 5A E9 AC 16
2
XX．XX
A
20
Conjuction active
power
68 99 99 99 99 99 99 68 01 02 63 E9 B5 16
3
XX．XXXX
kW
21
Phase A active
power
68 99 99 99 99 99 99 68 01 02 64 E9 B6 16
3
XX．XXXX
kW
22
Phase B active
power
68 99 99 99 99 99 99 68 01 02 65 E9 B7 16
3
XX．XXXX
kW
23
Phase C active
power
68 99 99 99 99 99 99 68 01 02 66 E9 B8 16
3
XX．XXXX
kW
24
Conjuction reactive
power
68 99 99 99 99 99 99 68 01 02 73 E9 C5 16
2
XX．XX
kvar
25
Phase A reactive
68 99 99 99 99 99 99 68 01 02 74 E9 C6 16
2
XX．XX
kvar

Acrel ACR10R Series Specifications

General

Model	ACR10R series
Communication	RS485, Modbus-RTU
Protection	IP20
Display	LCD
Power Supply	AC/DC
Rated Current	AC 1A, AC 5A
Frequency	45Hz - 65Hz
Accuracy class	0.5
Power consumption	<5VA
Operating temperature	+55°C
Storage temperature	-25℃~+70℃
Safety	IEC/EN 61010-1
EMC	IEC 61326-1
Relative Humidity	≤95% (non-condensing)
Voltage overload	1.2x rated voltage continuously, 2x rated voltage for 1 second
