Acrel APM Series User Manual

11
ULL
(line voltage)
U_Unablance (unbalance of line voltage)
Offset (Line voltage offset)
ULN
(phase voltage)
V_Unablance (Unbalance of phase
voltage)
offset (Phase voltage deviation)
Angle (Voltage phase angle)
P (active power)
Q (reactive power)
S (apparent power)
E (energy)
IMP (Absorb active energy)
See energy view
for details
EXP (Release active energy)
EQL (Inductive reactive energy)
EQC (Capacitive reactive energy)
d (current demand
for three-phase
current)
Current active power demand
See demand view
for details
Current reactive power demand
Current apparent power demand
Phase A current maximum demand and
time of occurrence
Phase B current maximum demand and
time of occurrence
Phase C current maximum demand and
time of occurrence
Active power maximum demand and time
of occurrence
Reactive power maximum demand and
time of occurrence
Apparent power maximum demand and
time of occurrence
PF (power factor)
THD
UH THD (Total harmonic distortion of
phase voltage)
2-63 harmonics
of three phase
voltage
See harmonics
for details
UH ODD (Total odd harmonic distortion
of phase voltage)
UH EVEN (Total even harmonic
