Acrel APM Series User Manual

42
The contents of the following address table are for Modbus TCP operation only. (Related to the slave information read by the user)
Register
(WORD)
Name
Resolution
Data type
(Read-write
attribute)
Note
39992-39993
Group 32-1 slave
status
Int32 (RO)
The high byte is first, the low byte
is after, bit0 is the first group
state, and 1 is the read failure,
and the corresponding cache is
cleared.
39994-39995
Group 64-33 slave
status
Int32 (RO)
The same as above
39996-39997
Group 96-65 slave
status
Int32 (RO)
The same as above
39998-39999
Group 128-97 slave
status
Int32 (RO)
The same as above
40000-57999
Information area
read from slave
station
RO
Example is as follow
58000
Read slave station
timeout
1ms
UInt16(RW)
Example is as follow
58001
Slave station access
interval time
1ms
UInt16(RW)
Example is as follow
58002
Group 1 slave
station address
UInt16(RW)
1-247 (Slave address station, does
not take effect when set to 0)
58003
Group 1
communication start
address
UInt16(RW)
0-65535
58004
Group 1
communication
length
UInt16(RW)
(Does not take effect when set to 0)
58005-58385
Group 2-128 slave
station settings
UInt16(RW)
Same as 58002-58004
58386-58399
Reserved
58400-58527
Failure rate
UInt16(RO)
Communication reads state of each
group, the slave access failure
rate of last 20 visits, 100% means
the disconnection and clear cache
58600-58728
Number of errors
UInt16(RO)
The cumulative number of failures
used to debug slave access
58800-58928
Number of
transmissions
UInt16(RO)
The cumulative number of
transmissions used to debug slave
access
E.g:
