Pulse output of energy
Output mode: Optocoupler pulse with open collector;
Pulse constant：4000（5A）、8000（1A） imp/kWh；
Analog outputs
DC 0mA～20mA、4mA～20mA、0V～5V、1V～5V output, accuracy class 0.5%, load
resistance ≤ 500Ω;
Analog inputs
DC 0mA
～
20mA
、
4mA
～
20mA
、
0V
～
5V
、
1V
～
5V iutput, accuracy class 0.5%
Storage card
Standard Capacity:4G,TF Card Up to 32G Capacity;
Communication
RS485 interface/Modbus-RTU protocol and DLT645 protocol
Profibus-DP interface/Profibus-DP protocol;
RJ45 interface (Ethernet) / Modbus-TCP, http, DHCP and other protocols;
Power supply
Working range: AC/DC 85V～265V or AC/DC 115～415V(P2);
Power consumption: Power consumption of the main part ≤ 15VA;
Safety
Power
frequency
withstand
voltage
The power frequency withstand voltage between the shell and the auxiliary power supply, each
input and output terminal group is AC 4kV/1min;
The power frequency withstand voltage between the auxiliary power supply and each input and
each output terminal group is AC 2kV/1min;
The power frequency withstand voltage between the voltage input and other input/output
terminal groups is AC 2kV/1min;
The power frequency withstand voltage between the current input and other input/output
terminal groups is AC 2kV/1min;
The power frequency withstand voltage between the relay output and other input/output terminal
groups is AC 2kV/1min;
The power frequency withstand voltage between each terminal group of switch input,
communication, analog output and pulse output is AC 1kV/1min;
Insulation
resistance
Inputs、outputs to the shell>100MΩ；
Electromagnetic compatibility
Meet IEC 61000 standard (Level 4);
Protection level
Display panel IP52
Environment
Operating temperature: -20 °C ~ +65 °C;
Storage temperature: -20°C
～
+70°C;
Relative humidity: ≤95% without condensation;
Altitude: ≤2500m;
Standards
IEC 60068-2-1
IEC 60068-2-2
IEC 60068-2-30
Environmental Testing-Part 2-1:Tests Test A:Cold IDA
Part 2-1:Tests Test B:Dry heat
Part 2-30:Tests Test Db:Damp heat,cyclic(12+12h)
IEC 61000-4
Electromagnetic compatibility-Testing and measurement techniques
IEC 61557-12
Electrical safety in low voltage distribution system up to 1000V a.c.
and1500V d.c –Equipment for testing,measuring or monitoring of
protective measures- Part12
：
Performances measuring and monitoring devices(PMD)
IEC 62053-22
Electricity metering equipment (a.c.)-Particular requirements -
Part22:Static meter for active energy（class 0.2s and 0.5s）
